Specifications
| test load | 100kg |
| Drop height | 300mm |
| Maximum specimen size | 1000*800*1000mm |
| Baseplate size | 1700*1200mm |
| Drop height error | ±10mm |
| Drop height error | 1% |
| Impact panel parallelism error | ≤1° |
| Drop plane error | <1° |
| Test method | Face, corner, edge |
| Power | AC380V±10% 50Hz 1P |
| Dimensions | 1700*1200*2715mm |
| Net Weight | 300kg |
Packing list
complete-built unit X1, manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 365 days
