Specifications
| Measurement principle | magnetic Induction |
| Measurement range | 0~1250μm |
| margin of error | ±3% |
| resolution | 0.1μm|1μm |
| Minimum measurement surface | Φ7mm |
| minimum radius of curvature | Convex 1.5mm; Concave 3mm |
| thinnest matrix | 0.5mm |
| probe | F split probe |
| statistical function | Measurement Times, MAX Maximum, MIN Minimum, Average, Standard deviation |
| icon function | without |
| Calibrated Certificate | without |
| system language | Chinese |
| Display screen | Back view, four-digit reading display, two-line statistical display, Chinese operation |
| companion software | without |
| Weight | 200g |
| Dimension | 140*65*30mm |
| Calibrated mode | Manufacturer calibrated, zero calibrated, calibrated foil calibrated |
| Operating temperature | 0~40℃ |
| Relative Humidity | 20~90%RH |
Packing list
host x1, probe x1, standard piece x5, substrate x1, alkaline battery x2, certificate x1, warranty card x1, manual x1, instrument case x1.
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/1382/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
