Specifications
| Maximum test force | 5KN, 10KN, optional within |
| Accuracy class | Level 0.5 |
| Force range | 0.4~100%F.S |
| Force value Accuracy | ±1%, ±0.5% |
| Force value resolution | The maximum load is 1/300000, the inside and outside are not divided into gears, and the whole resolution remains unchanged |
| Load Sensors | Basic configuration: one pull and pressure Sensors (maximum load), extended configuration: multiple Sensors can be added |
| Effective test width | 420mm (can be widened according to customer requirements) |
| Efficient stretch space | 400, 500mm (can be increased according to customer requirements) room temperature 900MM |
| Test speed range | 0.001~500mm/min |
| 位移Resolution | 0.2%～100%FS |
| Deformation measurement system | Exhibition configuration: large deformation: minimum gauge distance 10mm, deformation range: 800mm Large deformation error of indication: within ± 0.5% of indication; large deformation measurement resolution: 0.008mm |
| Deformation indication Accuracy | Within ± 0.5% of the indication |
| Test bench Safety Devices | Electronic limit protection |
| Deformation measurement system | Extended configuration: large deformation: minimum gauge distance 10mm, deformation range: 800mm Extended configuration: small deformation: gauge distance 25mm, 50mm, 100mm Deformation range: 5mm, 10mm, 25mm |
| Deformation measurement Accuracy | Within ± 0.5% of the indication (large deformation or small deformation can be selected according to customer requirements) |
| Force control speed adjustment range | 0.005～5%FS/s |
| Accuracy class | Level 0.5 |
Packing list
Host X1, manual X1, certificate X1, warranty card X1, standard tensile fixture X1 (group), special test software for tensile machine X1
After-sales instructions
Warranty days: 365 days
1. The manufacturer provides 1 year warranty, and the manufacturer will repair any product quality problems during the warranty period;
2. The manufacturer provides door-to-door delivery, installation and training services (corresponding travel expenses need to be charged);
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/14109/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
