Specifications
| Maximum test force | 50N、100N、200N、500N、1000N |
| Accuracy class | Level 0.5 |
| Force range | 0.4~100%F.S |
| Force value Accuracy | <±0.5％ |
| Force value resolution | The maximum load is 1/200000, the inside and outside are not divided into gears, and the whole resolution remains unchanged |
| Load Sensors | Basic configuration: one pull and pressure Sensors (maximum load), extended configuration: multiple Sensors can be added |
| Efficient stretch space | 400, 500mm (can be increased according to customer requirements) |
| Test speed range | 0.001~500mm/min |
| displacement resolution | Within ± 0.2% of the indication |
| Test bench Safety Devices | Electronic limit protection |
| Electronic limit protection | jog |
| Test bench return function | Manual or automatic two options, automatic or manual return to the initial position of the test at the highest speed after the test |
| Overload protection | 10% more than the maximum load, the machine is automatically protected |
| Fixture configuration | A set of stretching fixtures |
| Dimensions | 450*550*1400mmm |
| Motor type | Servo Motor Motor + Driver |
| Power | 220V、50HZ |
| power | 0.4KW (according to different force value requirements, standard with different power motors) |
| Host Weight | About 35Kg |
Packing list
Host X1, manual X1, certificate X1, warranty card X1, standard tensile fixture X1 (group), special test software for tensile machine X1
After-sales instructions
Warranty days: 365 days
1. The manufacturer provides 1 year warranty, and the manufacturer will repair any product quality problems during the warranty period;
2. The manufacturer provides door-to-door delivery, installation and training services (corresponding travel expenses need to be charged);
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/14125/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
