Specifications
| Liner size | 600*850*800mm |
| Dimensions | 1100*1710*1370mm |
| Liner material | 1.0mm stainless steel plate |
| Enclosure Material | SECC steel plate; 1.2mm; paint treatment |
| Thermal insulation material | Imported rock sponge |
| Rock wool Film thickness | 80mm |
| Temperature analysis Accuracy | ±0.5℃% |
| Temperature Uniformity | ±1.5℃% |
| Temperature range | RT-200°C |
| heating time | Room temperature~ 100 ℃ about 10 minutes |
| heater | Screw heater with heat sink |
| temperature Controller | PID microcomputer, automatic calculation, digital temperature Controller |
| Digital temperature Controller | 99.9 seconds - 999 hours (optional setting hours, minutes, seconds), a continuous use of b temperature to time, time to cut off the heating current (alarm device) (Taiwan, China YANGMING) |
| output Voltage | 12V |
| current Controller | SSR contactless RELAY |
| Timer | Up to 999 hours |
| ventilation Volume | 5~ 200 times/hour, measured at temperature 136 ℃ |
| Air Volume adjustment | A set of manually fine-tuned conical air Volume adjusters (the power consumption when the temperature is fixed is calculated in watt-hours and numbers) |
| Power | 220V single phase 50/60Hz |
| current | 27A |
| power | 5KW |
| Air supply method | horizontal air supply |
| Fan | Multi-blade turbine type |
| Intra-trough wind speed | About 1m per second |
Packing list
Host X1, manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. The manufacturer provides 1 year warranty, and the manufacturer will repair any product quality problems during the warranty period;
2. The manufacturer provides door-to-door delivery, installation and training services (corresponding travel expenses need to be charged);
