Specifications
| Power supply Voltage | AC 220V 50Hz |
| Heating mode | Electric heating film |
| Temperature range | RT+5~65℃ |
| Temperature Fluctuation | ±0.5℃ |
| Temperature Resolution | 0.1℃ |
| Environmental temperature | +5~35℃ |
| Input Power | 1100W |
| Liner size | 600*520*1300mm |
| Dimension | 780*760*1800mm |
| Timer Range | 1~9999min |
| Environmental humidity | 50%RH |
| Environmental temperature | +5~35℃ |
| Temperature Control mode | LCD temperature Controller |
| Temperature Control mode | Independent temperature limit Controller (optional) |
| Interface | RS485 interface and communication software (optional) |
| Temperature Control mode | Independent temperature limit Controller (optional) |
| Interface | Printer or 485 interface (optional) |
| Volume | 405L |
Packing list
Shelf X3, host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/14343/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
