Specifications
| Power supply Voltage | AC 220V 50Hz |
| Heating mode | water jacket |
| Temperature range | RT+5~65℃ |
| Temperature Fluctuation | ±0.5℃ |
| Temperature Resolution | 0.1℃ |
| Temperature Uniformity | ±1℃ |
| Power Consumption | 860W |
| Liner size | 500*500*650mm |
| Dimension | 650*650*950mm |
| Timer Range | 1~9999min |
| Environmental humidity | 50%RH |
| Environmental temperature | +5~35℃ |
| Temperature Control mode | Smart program LCD temperature Controller (optional) |
| Temperature Control mode | Independent temperature limit Controller (optional) |
| Interface | RS485 interface and communication software (optional) |
| Interface | Printer (optional) |
| Volume | 160L |
Packing list
Shelf X3, host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
