Specifications
| Temperature range | RT+10~250℃ |
| Temperature Fluctuation | ±1℃ |
| Temperature Resolution | 0.1℃ |
| Volume | 91L |
| Interior size | 450*450*450mm |
| Chamber material | Stainless steel (1Gr18Ni9Ti) |
| Shelf (std.) | 3pcs |
| Timer | 1~9999min |
| vacuum | <133Pa |
| Power supply Voltage | 220V 50Hz |
| Input Power | 1400W |
| Environmental temperature | RT+5~40℃ |
| Environmental humidity | 50%RH |
| Dimensions | 610*660*1400mm |
| Vacuum pump | Yes. |
| Heating mode | Shelf heating |
| Drying filtrate tank | optional |
| Gas-liquid separator | optional |
| Inert gas inlet | optional |
| Communication interface | RS-485 interface and communication software (optional) |
Packing list
Shelf X2 (independent temperature control), host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/14413/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
