Specifications
| Measurement principle | Magnetic induction + eddy current |
| Measuring range | 0 ~ 1250µm |
| margin of error | ±3% |
| resolution | 0.1µm |
| Minimum measurement surface | F26mm |
| Minimum radius of curvature | F: convex 1.5mm/concave 25mm; N: convex 3mm/concave 50mm |
| thinnest matrix | 0.3mm |
| probe | F and NF integrated probes |
| icon function | without |
| Power | 2 * AAA 1.5V battery |
| Standards | ISO2178、ISO2360、Gb4956、Gb4957 |
| Calibrated Certificate | without |
| Language | Chinese |
| Display screen | 4-Bit digital backlight LCD |
| supporting software | Yes (optional) |
| Total Weight | 90G (without battery) |
| Complete-built unit size | 130*63*24mm |
| Statistical function | Single measurement, continuous measurement |
| Operating Temperature | 0~50℃ |
| Optional accessories | RS-232C data cable interface, USB data cable output, Bluetooth Data output |
| Relative Humidity | <80% RH |
Packing list
host x1, wrist rope buckle x1, iron base x1, aluminum base x1, calibrated diaphragm x1 set, portable case x1, manual x1
After-sales instructions
Warranty days: 730 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/1461/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
