Specifications
| Optical inspection structure | Optical inspection system of full spectrum vacuum structure |
| Room temperature | Automatic control thermostatic: 35 ℃ +/- 0.5 |
| Wavelength range | 160-800nm |
| Grating focal length | 300 mm |
| Grating line | 3600 l/mm |
| Light spectrum Angular dispersion | 1.2 nm/mm |
| Detector | Multi-block high-performance linear array CCD |
| Average resolution | 30pm/pixel |
| gas | argon rush |
| Flow rate of argon | 3-5L/min during excitation |
| Electrode | Tungsten injection electrode technology |
| Purge | Click on the self-cleaning function |
| compensation | Thermal deformation self-compensating design |
| analysis gap | Sample stage analysis gap: 4mm |
| type | HEPS digitalization Solid State Light source |
| Frequency | 100-1000Hz |
| discharge current | 1-80A |
| special technology | Discharge parameter optimization design |
| preignition | High energy precombustion technology |
| processor | High-end ARM processor, high-speed data synchronization acquisition and processing |
| interface | Ethernet Data Transmission Based on DM9000A |
| input | 220VAC 50Hz |
| Power | Maximum 700W during analysis, 40W in standby state |
| Operating temperature | 10-30 ℃ (temperature change in this temperature range is not more than 5 ℃/h) |
| Operating humidity | 20-80% |
| Host size | 700*660*340 mm |
| Weight | About 30Kg |
Packing list
host x1, manual x1, certificate x1, warranty card x1
After-sales instructions
Warranty days: 365 days
1. Non-artificially caused product quality problems, the manufacturer provides 1 year free warranty service;
2. The manufacturer is responsible for lifelong maintenance and repair services for the products sold, and provides spare parts supply guarantee;
