Specifications
| PH range | -2.000~20.000pH |
| PH measurement Accuracy | ±0.002pH |
| resolution | 0.1/0.01/0.001pH/optional |
| Temperature compensation method | Automatic/Manual |
| Temperature Measurement range | 0~100℃/32~212℉ |
| Packaging Dimensions | 340*290*80mm |
| Encasement Weight | 1.5kg |
| mV calibrated range | ±200mV |
| ORP calibrated point | 1 point (only for R.mV mode) |
| PH calibrated | 1 to 5 point |
| Calibrating fluid | USA, NIST, DIN, custom |
| mV range | -1999.9~1999.9mV |
| mV measurement Accuracy | ±0.2mV |
| mV resolution | 0.1|1mV |
| Temperature Measurement range | 0~105℃/32~221℉ |
| Temperature measurement Accuracy | ±0.5℃ |
| temperature resolution | 0.1℃ |
| data lock | Manual or automatic end point locking |
| data storage | 500 groups |
| Communication interface | USB |
| Connector | BNC |
| Power | 3 AA batteries |
| Battery life | About 150 hours (when the LCD backlight is turned off) |
| Dimensions | 170*85*30mm |
| Weight | 300g |
| Optional accessories | E201-BNC type pH electrode, E202-BNC type pH electrode, pH standard buffer reagent (USA standard), TP-100K temperature probe |
| Packaging Dimensions | 340*290*80mm |
| Encasement Weight | 1.5kg |
| Temperature calibrating point | 1 point |
| Temperature unit | ℃, ° F, optional |
| Data stability condition | Fast or high precision |
| Calibrated reminder | 1 to 31 days or closed |
| shutdown mode | Manual or automatic (10, 20, 30 minutes after no button operation) |
| One-click reset function | contain |
| Optional accessories | P11 type pH electrode, P11-LiCl type pH electrode, P11-HA type pH electrode, P11-NA type pH electrode |
| Optional accessories | P12 type pH electrode, P13 type pH electrode, P15 type pH electrode, P16 type pH electrode, P18 type pH electrode, P19 type pH electrode, P21 type pH electrode, P22 type pH electrode |
| Optional accessories | Type 501 ORP electrode, Type 502 ORP electrode |
| Optional accessories | pH Standard Buffering Reagent (USA Standard), pH Standard Buffering Reagent (NIST Standard) |
| Optional accessories | TP-10K temperature probe |
Packing list
Host X1, plastic carrying case X1, AA battery X1, pH standard buffer (pH4.01/7.00/10.01) X1, TP-10K temperature probe X1, P11 pH electrode (made in UK) X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/14696/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
