Specifications
| Optical inspection system | C-T |
| Light spectrum Bandwidth | 0.05nm-5nm |
| Wavelength range | 190~2800nm |
| Wavelength Precision | ±0.5nm（UV/VIS）;±5nm（NIR） |
| Wavelength Repeatability | 0.3nm |
| Photometric range | 0.300~2.5A |
| Photometric Precision | ±0.3%T(0~100%T) |
| Luminosity Repeatability | 0.2%T |
| stray light | ≤0.2%T@220nm |
| Baseline flatness | +/- 0.008A (200~2500nm, after 30 minutes of preheating) |
| Dimensions | 830*600*260mm |
| test mode | Absorption, reflectance, energy |
| Scan step | 0.01nm |
Packing list
Host x1, supporting tools X1, application software X1, USB data cable X1, quartz Colorimetric dish X1, zero block X1, manual x1, certificate x1, warranty card x1
After-sales instructions
Warranty days: 1095 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/14726/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
