Specifications
| PH range | -2.000~20.000pH |
| PH measurement Accuracy | ±0.002pH |
| resolution | 0.1/0.01/0.001pH/optional |
| Temperature Measurement range | 0~100℃/32~212℉ |
| Power | DC12V power adapter |
| Dimensions | 210*188*60mm |
| Weight | 1.5kg |
| PH calibrated | 1 to 5 point |
| Calibrating fluid | USA, NIST, DIN, custom |
| mV range | -1999.9~1999.9mV |
| mV measurement Accuracy | ±0.2mV |
| mV resolution | 0.1|1mV |
| ORP calibrated point | 1 point (only for R.mV mode) |
| mV calibrated range | ±200mV |
| Temperature Measurement range | 0~105℃/32~221℉ |
| Temperature measurement Accuracy | ±0.5℃ |
| temperature resolution | 0.1℃ |
| Temperature calibrating point | 1 point |
| Temperature unit | ℃, ° F, optional |
| data lock | Manual or automatic end point locking |
| Data stability condition | Standard or high precision |
| Calibrated reminder | 1 to 31 days or closed |
| shutdown mode | Manual or automatic (10, 20, 30 minutes after no button operation) |
| One-click reset function | contain |
| data storage | 500 groups |
| Communication interface | USB |
| Connector | BNC |
| Display | Customized LCD (130 * 110mm) |
| Optional accessories | P11 type pH electrode, P11-LiCl type pH electrode, P11-HA type pH electrode, P11-NA type pH electrode, P12 type pH electrode, P13 type pH electrode, P15 type pH electrode, P16 type pH electrode, P18 type pH electrode, P19 type pH electrode, P21 type pH electrode, P22 type pH electrode, 501 type ORP electrode, 502 type ORP electrode |
| Temperature compensation method | Automatic/Manual |
Packing list
Host X1, E201-BNC type pH electrode X1, TP-10K type temperature probe X1, pH standard buffer reagent (pH4.01/7.00/10.01) X1, USB cable X1, DC5V power adapter X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/14759/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
