Specifications
| PH range | -2.000~20.000pH |
| PH measurement Accuracy | ±0.002pH |
| resolution | 0.01/0.001pH/optional |
| Temperature Measurement range | 0~100℃/32~212℉ |
| Power | DC12V power adapter |
| Dimensions | 240*200*80mm |
| Weight | 1.7kg |
| PH calibrated | 1 to 5 point |
| Calibrating fluid | USA, NIST, DIN, custom |
| mV range | -2000~2000mV |
| mV measurement Accuracy | ±0.2mV |
| mV resolution | 0.1mV |
| ORP calibrated point | 1 point (only for R.mV mode) |
| ORP measurement mode | Relative or absolute mV |
| Temperature Measurement range | 0~105℃/32~221℉ |
| Temperature measurement Accuracy | ±0.5℃ |
| temperature resolution | 0.1℃ |
| Temperature calibrating point | 1 point |
| Temperature unit | ℃, ° F, optional |
| data lock | Manual or automatic end point locking |
| Data stability condition | Standard or high precision |
| Calibrated reminder | 1 to 31 days or closed |
| Interval reading | 10, 30, 60 seconds, 10, 30 minutes or off |
| One-click reset function | contain |
| data storage | 1000 groups |
| Communication interface | USB |
| Connector | BNC |
| Display | 7-Inch TFT LCD |
| Optional accessories | P11 type pH electrode, P11-LiCl type pH electrode, P11-HA type pH electrode, P11-NA type pH electrode |
| Optional accessories | P12 type pH electrode, P13 type pH electrode, P15 type pH electrode, P16 type pH electrode, P18 type pH electrode, P19 type pH electrode, P21 type pH electrode, P22 type pH electrode |
| Optional accessories | TP-10K temperature probe, 501 type ORP electrode, 502 type ORP electrode, pH standard buffer reagent (USA standard), pH standard buffer reagent (NIST standard) |
| Packaging Dimensions | 300*240*170mm |
| Encasement Weight | 2kg |
| Ion Measurement range | 0~30000Ppm, mg/L, mol/L (please refer to the ion electrode description for the actual range) |
| Ion measurement Accuracy | ± 0.5% F. S (primary ion), ± 1% F. S (secondary ion) |
| Ion display resolution | 0.001, 0.01, 0.1, 1 |
| Ion calibrated point | 2 to 5 point |
| Ion measurement mode | Direct reading method, known addition method, known reduction method, sample addition method, sample reduction method |
| Hardness Measurement range | 0.05~200mmol/L |
| Hardness measurement Accuracy | ±1% F.S |
| Water Hardness Display Resolution | 0.001, 0.01, 0.1, 1 |
| Hardness calibrated point | 2 to 5 point |
| Water Hardness Measurement Units | ° dH, ° e, ° fH, mg / L, mmol / L |
| Temperature compensation method | Automatic/Manual |
Packing list
Host X1, P11 pH electrode (made in the UK) X1, TP-10K temperature probe X1, pH standard buffer reagent (pH4.01/7.00/10.01) X1, DC12V power adapter X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/14763/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
