Specifications
| Measurement range | 0.01~200mS/cm |
| resolution | 0.001, 0.01, 0.1, 1 |
| Power Supply | DC9V power adapter |
| Dimension | 210*205*75mm |
| Weight | 1.5kg |
| Measurement Accuracy of conductivity | ±1%F.S |
| Calibrating point | 1~ 3 points |
| Use calibrating fluid | 10µS/cm, 84µS/cm, 1413µS/cm, 12.88mS/cm, 111.8mS/cm |
| TDS Measurement range | 0~100ppt (Max. 200ppt) |
| TDS Measurement Accuracy | ±1% F.S. |
| TDS conversion factor | 0.1~ 1.0 (default 0.5) |
| Measurement range | 0~105℃ |
| Measurement Accuracy | ±1℃ |
| Display resolution | 0.1℃ |
| Temperature calibrating point | 1 point |
| Temperature unit | ℃/℉ |
| Temperature compensation range | 0~100℃ |
| Temperature compensation coefficient | 0.0~10.0%/℃ |
| Conductivity Detector cell constant | K = 0.1, 1, 10, custom |
| Standardized temperature | 25℃ |
| data lock | Manual or automatic end point locking |
| shutdown mode | Manual/Automatic |
| One-click reset function | contain |
| Connector | 6-Pin MINI Connector |
| Display | Customized LCD screen (135 * 75mm) |
| Optional Accessories | TP-10K temperature probe, Conductivity Detector standard solution, CON-0.1 type Conductivity Detector electrode, CON-1 type Conductivity Detector electrode, CON-10 type Conductivity Detector electrode, |
| Packaging Dimensions | 300*240*170mm |
| Encasement Weight | 1.7kg |
| Temperature compensation method | Manual/Automatic |
| material | plastic |
| principle | Electrode measurement solution conductivity, conversion conductivity and TDS value. |
| function | Measurement of solution conductivity and TDS value, analysis of water concentration. |
Packing list
Host X1, Con-1 Conductivity detector electrode X1, Con-10 Conductivity detector electrode X1, Conductivity detector standard solution (84 µS/cm, 1413 µS/cm, 12.88mS/cm) X1, TP-10K temperature probe X1, DC9V power adapter X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/14804/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
