Specifications
| PH range | -1.00~15.00pH |
| PH measurement Accuracy | ±0.01pH |
| resolution | 0.01pH |
| Temperature Measurement range | 0~100℃/32~212℉ |
| Power | DC24V |
| Dimensions | 96*96*75mm |
| Weight | 350g |
| Calibrated | 1 to 3 point |
| Calibrating fluid | USA (pH4.01/7.00/10.01)或NIST (pH4.01/6.86/9.18) |
| mV range | -1000~1000mV |
| mV measurement Accuracy | ±1mV |
| mV resolution | 1mV |
| Temperature Measurement range | 0~100℃/32~212℉ |
| Temperature measurement Accuracy | ±1℃ |
| temperature resolution | 0.1℃ |
| Signal output range | 4~ 20mA, maximum load 500Ω |
| High/low alarm settings | 0.00~14.00pH |
| Communication interface | RS485 |
| Allowable environment temperature | 0~60℃ |
| Optional accessories | IE-20T type industrial pH electrode, pH standard buffer reagent (USA standard), pH standard buffer reagent (NIST standard) |
| Packaging Dimensions | 260*200*110mm |
| Encasement Weight | 1.5kg |
| Temperature compensation method | automatic |
Packing list
Host X1, IE-20T type industrial pH electrode X1, pH standard buffer reagent (pH4.01/7.00/10.01) X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/14832/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
