TQC SP0505 Konig swing rod for sp0500/sp0501 Pendulum Hardness Tester

SP0505

Konig swing rod

TQC's pendulum Hardness Tester is a modular system. The instrument itself can be used for both the König and Persoz methods. Both pendulums should be ordered separately. Once the correct pendulum is placed, you can switch between the two measurement methods at the touch of a button. The pendulum is positioned completely automatically by means of a stepper motor. The release of the pendulum is also achieved by an electromagnetic system. The end of the test is indicated by visual and acoustic signals.

The TQC pendulum Hardness Tester is available in 110VAC/50/60Hz and 230VAC/50Hz models.

Ordering Information

The principle of pendulum hardness

The swing of the pendulum pin on different soft and hard surfaces is different, and the softer the surface swing weakens faster, and vice versa. The pendulum Hardness Tester is designed based on this principle.

There are two types of pendulum rods for the pendulum Hardness Tester, the Konig pendulum (Koenig pendulum) and the Persoz pendulum (Persaz pendulum). They work the same way, but the periodicity, amplitude and pin size of the oscillation are not the same.

Packing list：Konig swing bar × 1

[Note]Because the manufacturer's packaging may be updated or upgraded, the detailed packaging list shall be subject to the latest standard configuration of the manufacturer.
