Specifications
| Precision | Color product coordinates ≤ 0.001, the rest 0.01 |
| Repeatability | Rx, Ry, Rz ≤ 0.03, chromaticity coordinates ≤ 0.001, R457 ≤ 0.03 |
| Mirror reflection error | ≤0.1 |
| Dimensions | 380285*400mm |
| Net Weight | 15kg |
| Power Supply | AC(100~240)V，(50/60)Hz |
| Operating temperature | 10~35℃ |
| Specimen size | Test plane ≥ 0019 30mm, thickness ≤ 40mm |
| Indication Stability | 30min after preheating, within the temperature range of +/- 5 ℃, ≤ 0.1 |
| printout | Built-in thermal printer |
| Interface | Optional RS232 |
| Optional accessories | Whiteboard (3 #), Simple Powder Press, Glass Cover |
| Relative Humidity | ≤85%RH |
Packing list
host X1, black cylinder X1, whiteboard (1 #, 2 #) X1, light bulb X1, printing paper X1, power cord X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
The instrument comes with a one-year warranty free of charge, and lifetime maintenance (except for human factors)
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/14916/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
