Specifications
| Power supply Voltage | AC(100~240)V，(50/60)Hz |
| Operating Environment | Temperature (10~35) ℃, Relative Humidity < 85% |
| Measurement range | 0~500N |
| Indication resolution | 0.1N |
| Error of indication | ±1.0% |
| Working Travel | (35~300)mm / (35~500)mm |
| Specimen length (chuck spacing) | (35~ 180) mm/(35~ 300) mm (optional adjustment) |
| Specimen width | 15Mm (25mm, 50mm can be replaced with the chuck, need to book) |
| stretching speed | (1~ 480) mm/min (can be adjusted arbitrarily) |
| Print function | Built-in thermal printer |
| Communication interface | RS232 |
| Dimensions | 400*300*800mm |
| Net Weight of instrument | 35kg |
Packing list
host X1, printing paper X1, power cord X1, 15mm chuck X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
The instrument comes with a one-year warranty free of charge, and lifetime maintenance (except for human factors)
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/14921/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
