Specifications
| Power supply Voltage | AC(100~240)V，(50/60)Hz |
| Operating Environment | Temperature (10~35) ℃, Relative Humidity < 85% |
| Measurement range | 0~99999 times |
| folding angle | 135±2° |
| folding speed | 175±5CPM |
| crease radius | 0.38±0.02mm |
| Spring tension | 4.91/9.81N/14.72N |
| Folding mouth seam distance | 0.25mm/0.5mm/0.75mm/1.00mm |
| printout | Built-in thermal printer |
| Communication interface | RS232 |
| Dimensions | 265*270*525mm |
| Accessories | Weight chuck and dial kit (customizable), RS232 interface and microcomputer software |
Packing list
Host X1, large weight X1, small weight X1, folding chuck X1, printing paper X1, power cord X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
The instrument comes with a one-year warranty free of charge, and lifetime maintenance (except for human factors)
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/14923/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
