Specifications
| Measurement range | 1~500mN.m |
| error of indication | +/- 2% (10% to 90% of the upper limit of each measurement) |
| Indication variability | ≤ 2% (10% to 90% of the upper limit of each measurement) |
| Swing arm length | 100mm |
| network speed | （50±0.1）mm |
| Test speed | 200°±20°/min |
| bending angle | 7.5°±0.3、15°±0.3 |
| Specimen size | 70*38mm |
| environmental conditions | Temperature 20~40 ℃, Relative Humidity < 85% |
| Dimension | 230*290*330mm |
| Net Weight | 19.5 kg |
Packing list
Host X1, standard weight X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/14925/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
