Specifications
| Power supply Voltage | AC(100~240)V，(50/60)Hz |
| Operating Environment | Temperature (10~35) ℃, Relative Humidity < 85% |
| Measurement range | 15~10000mN.m |
| Error of indication | Below 50mN +/- 0.6mN, remaining +/- 1% |
| Resolution | 0.1mN |
| Indication variability | ≤1％ |
| bending length | 50mm、25mm、20mm、15mm、10mm、5mm(±0.1mm) |
| bending angle | Adjustable from 0 to 90 degrees, commonly used 15 degrees/7.5 degrees |
| Test speed | 3S-30s (adjustable at 15 °) |
| printout | Built-in thermal printer |
| Communication interface | RS232 |
| Dimensions | 310*245*300mm |
| Net Weight | 13kg |
| Optional accessories | Stiffness Sampler, RS232 interface and microcomputer software (optional) |
Packing list
Host X1, standard weight X1, printing paper X1, power cord X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
The instrument comes with a one-year warranty free of charge, and lifetime maintenance (except for human factors)
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/14926/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
