Specifications
| Power supply Voltage | AC(100~240)V，(50/60)Hz 50W |
| Operating Environment | Temperature (10~35) ℃, Relative Humidity ≤ 85% |
| show | 7-Inch color touch screen |
| Measurement range | 10~1000mN |
| Indication resolution | 0.1mN |
| Error of indication | +/- 1% (range 5%~ 100%) |
| Probe total travel | 12±0.5mm |
| Probe indentation depth | 8mm |
| Seam width of sample table | 5/6.35/10/20mm (four gear adjustable) |
| Slot-die parallelism error | ≤0.05mm |
| Probe alignment error | ≤0.05mm |
| Thermal printer | |
| Communication interface | RS232 (default) (USB, WIFI optional) |
| Dimensions | 425×290×300 mm |
| Net Weight of instrument | About 20kg |
Packing list
Host X1, weight X1, printing paper X1, power cord X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
The instrument comes with a one-year warranty free of charge, and lifetime maintenance (except for human factors)
