Specifications
| Power supply Voltage | AC(100~240)V，(50/60)Hz |
| Measurement range | 0~5mm |
| Resolution | 0.001mm |
| Error of indication | ±0.0025mm/±0.5％ |
| Indication variability | ≤ 0.0025Mm or ≤ 0.5% |
| Measurement plane parallelism | ≤0.002mm |
| Contact area | 200±5mm² |
| Contact Pressure | 100±10kPa |
| Probe descent speed | Adjustable from 0.5 to 10mm/s |
| Print function | Built-in thermal printer |
| communication output | RS232 |
| Dimensions | 320*310*400mm |
| Weight | 26.5kg |
Packing list
Host X1, printing paper X1, power cord X1, RS232 interface and microcomputer software (purchased separately) X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
The instrument comes with a one-year warranty free of charge, and lifetime maintenance (except for human factors)
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/14942/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
