Specifications
| Measurement range | 50 ~ 7600µm |
| Probe style | Split probe |
| Lower limit of pipe measurement | 500µm |
| Measurement error | ± (3% H + 20) μm |
| unit system | μm/mils |
| Storage Capacity | 100000 Measured values, 1000 groups |
| Statistical function | Average, standard deviation, Min/Max Film thickness and number of readings |
| Standards | ASTM D6132,ISO 2808 |
| Display | Color LCD |
| Operating language | English, Chinese |
| Interface | USB |
| Application software | Yes. |
| Protection level | Resistant to solvents, acids, oils, water and dust |
| Power | 3 * 7 battery |
| Host size | 127 x 66 x 25.4 mm |
| Weight | 137G (without battery) |
| Application | Thick soft coatings such as polyurea, asphalt, neoprene, very thick polymers, etc |
| calibration standard | Defesko STDP1 |
Packing list
host x1, probe x1, standard foil x1, coupling agent x1, rubber protective cover with waist clip x1, No. 7 battery x3, nylon portable soft bag x1, English manual x1, certificate x1.
After-sales instructions
Warranty days: 365 days
Non-artificially caused product quality problems, the manufacturer will be free of charge during the warranty period, and only the cost of spare parts will be charged outside the warranty period;
1-year warranty for the host and 6-month warranty for the probe, except for other accessories and consumables;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/1496/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
