Specifications
| Temperature Measurement Range | -20~280℃ |
| Accuracy | ±2% |
| Spatial resolution | 3.4Mrad (minimum measurable object size: 5.1mm) |
| Power Battery | Lithium battery (can be replaced on site) |
| Infrared resolution | 160*120pixel |
| Field of view | 31°×23° |
| Super infrared super pixel | 320X240 |
| Super-IDOV (Wide Angle) | 2.1Mrad (the minimum measurable object size is optimized to be 3.15mm) |
| minimum focal length | 0.5m |
| Focus method | Fixed autofocus |
| Thermal Sensitivity | <0.12℃ |
| Wavelength range | 7.5~14μm |
| Display | 3.5LCD |
| Color matching board | 4 kinds |
| image adjustment | Manual/Automatic |
| Cold/hot spot automatic search function | √ |
| Temperature difference function | √ |
| Temperature scale setting assistant | √ |
| IFOV warning device | √ |
| Interface | USB |
| storage device | Built-in (2.8GB) |
| file format | BMT/JPGE (export format BMP/JPG/PNG/CSV/XLS) |
| Battery life | 4 hours |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/14970/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
