Specifications
| PH range | 0.00~14.00pH |
| Temperature compensation method | automatic |
| Dimensions | 96*96*115mm |
| Minimum resolution | 0.01 pH |
| Precision | ±0.2pH |
| inlet pressure | 0~0.5 MPa |
| medium temperature | 5~50 ℃ |
| Output signal | 4~ 20 mA, maximum load 500Ω |
| Installation method | embedded |
| Panel opening size | 91 × 91mm |
| PH electrode mounting size | 3/4 "Pipe Thread |
| Cable length | Regular 5m or otherwise agreed |
| Calibration method | two-point correction |
Packing list
host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/15019/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
