Specifications
| Measurement range | Channel A: conductivity 0~10.00 mScm~ 1, Channel B: conductivity 0~100 μS • cm~ 1 |
| Temperature compensation range | 5~50℃ |
| Dimensions | Height 96 * Width 96 * Depth 115mm |
| Intrinsic error | +/- 3% (FS) +/- 1 word |
| inlet pressure | 0 ~ 0.5 MPa |
| Output signal | 4~ 20 mA, maximum load 500Ω |
| Installation method | embedded |
| Panel opening size | 91 × 91mm |
| Electrode mounting thread | 1/2 "pipe thread |
| Cable length | Regular 5m or otherwise agreed |
Packing list
host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/15020/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
