Specifications
| Measurement principle | magnetic Induction |
| Measurement range | 0~3000μm |
| margin of error | ±5% |
| resolution | 1µm|2µm|5µm |
| Minimum radius of curvature | Convex 25mm; Concave 50mm |
| thinnest substrate | 0.75mm(F) |
| probe | F integrated probe |
| Power Supply | 90 grams including battery |
| Standards | DIN、ISO、ASTM、BS |
| Weight | 90G (including battery) |
| Dimension | 110*50*25mm |
| testing environment | Iron/steel |
| Calibrated mode | Manufacturer calibrated |
| Operating temperature | 0~50℃ |
| Probe contact temperature | -15~60℃ |
| Minimum headroom | 125mm |
| Minimum measurement surface | 40*40mm |
| Protection level | IP52 |
Packing list
Measurement instrument x1, test foil 200 microns x1, zero standard sheet x1, material package x1, rubber protective cover x1, battery x2, user manual x1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/1518/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
