Specifications
| PH range | -2.00~16.00pH |
| Measurement Accuracy | +/- 0.1% +/- 1 word |
| Resolution | 0.01pH |
| Power Supply | 110或230VAC,50/60Hz |
| Dimensions | 96*96*148mm |
| PH standard solution | US (4.01, 7.00, 10.01) or (4.00, 6.86, 9.18) user-selected, automatic two-point correction |
| Data storage for pH correction | Yes. |
| Current output range | A set of 4~ 20mA reversible, isolated current outputs |
| Insulation Voltage/maximum load | 1000VDC/550Ω |
| opening size | 92*92mm |
| protective measures | 4-Digit password protection |
| Relay Control Output/Maximum Load | Two sets of ON/OFF control in the system 2.5A/230VAC |
| Measurement range mV | -2500~2500mV |
| mV resolution | 1mV |
| Measurement Accuracy of mV | ±0.1%F.S |
| Measurement range | -10.0~120.0℃ |
| Temperature Resolution | 0.1℃ |
| Measurement Accuracy | ±0.3℃ |
| Shop Accessories | PH electrode, ORP electrode, mounting bracket, sealing box |
Packing list
Host X1, IP-600-10 (20 meters) X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
The manufacturer provides a 1-year warranty for the instrument and 1 month for consumables such as electrodes (except for human factors)
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/15181/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
