JENCO 3331 resistivity temperature transmitter 0.000uS/cm~ 19.99mS/cm

SE
Isolation 4~ 20mA, 0~20.0mS/cm, backlit LCD display 1600.00 (stand-alone)
Model：
Certificate
Contact
Details SPEC CAT OI

JENCO 3331 Resistivity temperature transmitterSPEC

JENCO 3331 Resistivity temperature transmitterDetails

JENCO 3331 Resistivity temperature transmitterPacking list

SKU
NB015186
Measurement range
0.000uS/cm~19.99mS/cm
Resolution
0.001uS/cm
Accuracy
0.5% +/- 1 word
Types of electrode constants
0.01, 0.1, 1.0 (2-wire Conductivity Detector electrode)
reference temperature
25.0 ℃, factory setting
current output
A set of isolated 4~ 20mA analog outputs
Dimensions
1/4DIN standard body, 96 * 48 * 110mm
opening size
92*45mm
Power Supply
100~240VAC,50/60Hz
Weight
200g
Shop Accessories
Conductivity electrode, password box
3331
Resistivity temperature transmitter
Isolation 4~ 20mA, 0~20.0mS/cm, backlit LCD display 1600.00 (stand-alone)
JENCO 3331 resistivity temperature transmitter 0.000uS/cm~ 19.99mS/cm Picture

JENCO 3331 Online Conductivity Resistivity Temperature Transmitter Features

  • Standard 1/8DIN design correction value power-off memory function

  • With LCD backlit display

  • 4~20mA Isolated Current Output(3331)

  • Group 2 (Conductivity, Resistivity) Electrical Control(3321)

  • Automatic/manual temperature compensation function

  • CE marked

Ren's 3331 resistivity temperature transmitter

Optional


ModelIntroduction
Conductivity electrodes392-122Pure water ultrapure water treatment field (can be used below 80°C for a long time)
392-126Pure water ultrapure water treatment field (can be used below 80°C for a long time)
392-125Circulating water and general water treatment (can be used below 80°C for a long time)
EC621-001Pure water ultrapure water treatment field (can be used below 120°C for a long time)
EC621-01Pure water ultrapure water treatment field (can be used below 120°C for a long time)
Sealed box011-150-00Dial-mounted
012-150-00Wall-mounted


FAQ
QDoes the JENCO resistivity temperature transmitter meet the HG/T2003 standard?
A The 3331 resistivity temperature transmitter can refer to
