Specifications
| test range | 1~3500μm |
| Camera resolution | 2048 × 1536 pixels |
| system magnification | 4000 times |
| Repeatability Error | < 2% (excluding error due to sample prepative factors) |
| System resolution | 0.1 micron |
| Digital Camera (CCD) | 5 million pixels |
| Microscope | Microscope |
| Ruler scale | 10μm |
| Camera system | Maximum resolution 2048 × 1536; pixel size 2.2µm × 2.2µm; frame rate 5FPS; signal-to-noise ratio 40.5dB; sensitivity 0.53V/lux-sec; output mode USB2.0 |
| calibration function | Use ruler calibration to make measurement results accurate |
| Automatic segmentation, multiple images merge function | The software has automatic segmentation and manual segmentation functions, among which the automatic segmentation function is convenient, accurate and fast; the software adopts the function of merging multiple pictures to make up for the shortcomings of insufficient representation of the image particle size instrument |
| analysis project | Particle size distribution, aspect ratio distribution, circularity distribution, monomer particles and particle groups, etc |
| Automatic segmentation speed | < 1 second. Segmentation success rate: > 93% |
| Software operating environment | Windows XP、Windows7 |
| interface mode | USB mode |
| Output item | Including original parameters (including sample information, test information, etc.), analytical data (including interval distribution, cumulative distribution, average diameter, aspect ratio, and aspect ratio distribution, etc.), distribution graphics (interval distribution histogram and cumulative distribution Linear dispersion, etc.) |
Packing list
OpticalMicroscopy X1, industrial digital CCD camera X1, image processing and analysis software X2, ultrasonic disperser X1, sample spoon X3, slide X1, coverslip X1, power strip X1, paper drawing X1, warranty card X1, manual X1, certificate X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/15263/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
