Specifications
| principle | Sufficient overflow of dust into the tray from the hopper mouth to the horizontal tray; measurement of dust accumulation slope and the bottom of the horizontal plane between the acute angle, that is, the dust resting angle. |
| Funnel outlet diameter | 5mm |
| Funnel taper | 60º±0.5º |
| protractor | 10cm |
| chassis | The distance between the bottom of the outflow port and the plate surface is 80mm +/- 2mm, and the diameter of the material plate is φ 80mm. |
| Repeatability Error | ≤1% |
Packing list
machine X1, clogging rod X1, overflow funnel X1, sample table X1, sample spoon X1, brush X1, warranty card X1, manual X1, certificate X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/15270/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
