Specifications
| Transmission mode | gear drive |
| Operating Mode | Two or four ball milling tanks work simultaneously |
| Maximum sample loading | Two-thirds of the Volume of the ball mill tank |
| Ball mill tank Volume | 0.05L-25L per can, total Volume 0.2L-100L |
| Feed particle size | Soil material ≤ 10mm, Miscellaneous material ≤ 3mm |
| Minimum discharge particle size | 0.1μm |
| Speed regulation mode | Frequency conversion stepless speed regulation |
| Processing Capacity | 8L |
| Can be equipped with ball mill tank specifications | 1~2L |
| station number | 4pcs |
| Can be equipped with ball mill tank specifications | 0.05~1.5L |
| Power | 220V-50HZ |
| Inverter Power | 1.5kw |
| Total running time | 1-9999min |
| alternate running time | 1~999min |
| Adjustable Rotation speed - revolution | 35~290rpm |
| Noise level | 60±5dB |
| Motor Power | 1.5kw |
| Speed regulation mode | Frequency conversion speed regulation |
| Device Weight | 420kg |
| Equipment Volume | 1360*850*930mm |
| Adjustable Rotation speed - Rotation | 70~580rpm |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
