Specifications
| Impact height | 1265mm |
| Drop weight mass | 1000G, 2 pounds |
| Punch diameter | Φ15.9mm、Φ20mm |
| Impact depth | 10mm |
| die base aperture | Φ27mm、Φ17mm |
| Table size | 300*240*35mm |
| Meet the standard | ISO6272M, ASTMD2794, NCCA ⅱ-10 (ⅱ-6, ⅱ-16) and X-1, ECCA Meth. No. 5, NFT30-039, etc |
| Instrument net weight | 18kg |
Packing list
Host x1; 1kg weight, punch steel ball diameter φ 20mmx1; 1kg weight add-on x1; 2lbs weight, punch steel ball diameter φ 15.9mmx1; 2ibs weight add-on x1; φ 27mm die base (on the host) x1; φ 0.7in die base x1; height limit ring and screw x 1 each; a set of depth control rings (4 in total)
After-sales instructions
【Attention】
The purchase of this product is calculated from the date of the purchase contract, and the warranty period is 1 year, and the freight is borne by the customer during the warranty period.
Damage caused by improper use is not covered by the warranty.
