Specifications
| test force | 187.5kgf、250kgf、750kgf、1000kgf、3000kgf，1838.3N、2451.8N、7355.3N、9807N、29421N |
| Measurement range | 8-650HBW |
| reading | look-up table |
| Maximum height of specimen | 230mm |
| Distance from the center of the indenter to the machine wall | 120mm |
| Power Supply | AC 380/220 volts |
| Dimension | 700*268*842mm |
| Weight | 210kg |
Packing list
The whole machine X1, big flat test bench X1, V-shaped test bench X1, φ 5 steel ball indenter X1, standard brinell hardness block X2, weight X1 (set), Xiaoping test bench X1, φ 2.5 steel ball indenter X1, φ 10 steel ball indenter X1, 20 times reading Microscope X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/15415/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
