Specifications
| Brinell scale | HBW2.5/62.5、HBW2.5/187.5、HBW5/125、HBW5/750、HBW10/100、HBW10/1500、HBW10/3000、HBW10/250、HBW10/500、HBW10/1000 |
| test force | 62.5kgf、100kgf、125kgf、187.5kgf、250kgf、500kgf、750kgf、1000kgf、1500kgf、3000kgf（612.9N、980.7N、1226N、1839N、2452N、4903N、7355N、8907N、14710N、29420N） |
| Conversion ruler | HV、HK、HRA、HRB、HRC、HRD、HRE、HRF、HRG、HRK、HR15N、HR30N、 HR45N、HR15T、HR30T、HR45T |
| Measurement unit | 0.001mm |
| Hardness testing range | 8~650HBW |
| Microscope magnification | 20X |
| execution standard | ISO 6506、ASTM E10-12、JIS Z2243、GB/T 231.2 |
| Maximum height of specimen | 225mm |
| Distance from the center of the indenter to the body | 135mm |
| Hardness reading | Digital LCD Reading Hardness |
| Interface | Built-in printer, RS232 interface |
| Power Supply | AC220+5%、50~60Hz |
| Dimension | 786*565*245mm |
| Host Weight | 130kg |
Packing list
The whole machine X1, 20X micrometer eyepiece X1, < unk > 5mm cemented carbide ball indenter X1, standard Hardness block X3, medium test bench X1, fuse X2, RS232 wiring X1, < unk > 2.5mm cemented carbide ball indenter X1, < unk > 10mm cemented carbide ball indenter X1, large test bench X1, V-shaped table X1, power cord X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/15417/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
