Specifications
| test force | 61.25N(6.25kgf),98.07N(10kgf),153.2N(15.625kgf), 294N(30kgf),306.25N(31.25kgf),612.9N(62.5kgf) |
| execution standard | EN, ISO 6507, EN ISO 6506, ASTM E-384, ASTM E-10-08, ASTM E-384 GB/T231.2，JJG150 |
| Maximum height of specimen | 160mm |
| Head to wall distance | 135mm |
| Dimension | 250*550*650mm |
| Test force holding time | 5~60s |
| Test force application method | automatic |
| Microscope magnification | 40x，100x |
| Hardness Measurement range | 8-650 HBW |
| Power Supply | AC220V/50HZ |
| Weight | 45kg |
Packing list
The whole machine X1, the first 1mm steel ball head X1, the first 5mm steel ball head X1, brinell hardness block X2, fuse X2, thermal printing paper X1, the second 2.5mm steel ball head X1, large test table X1, flat test table X1, V-shaped test table X1, weight X1 (set), power cord X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/15418/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
