Specifications
| objective lens | LMPL5X/0.15 WD11mm，LMPL10X/0.3 WD9.5mm，LMPL20X/0.45WD3.4mm，LMPLFL50X/0.55 WD7.5mm |
| Total Magnification | 50X, 100X, 200X, 500X adjustable (standard 10X eyepieces) |
| converter | Inner positioning 5 holes |
| lighting system | Reflection lighting system (12V100W halogen lighting), adjustable luminance |
| Halogen lamp | 12V/100W |
| Halogen lamp | 12V/100W |
| Mobile Platform | Low hand position X, Y direction coaxial adjustment |
| workbench | 445mmX240mm |
| range of motion | 158mmX158mm |
| Polarizer insert board | Φ30 |
Packing list
Machine X1, eyepiece X1, tee X1, objective X4, converter (with DIC slot) X1, reflection rack X1, thermal insulation system X1, halogen light box X1, halogen light X1, mobile platform X1, plug board X2, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/15499/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
