Specifications
| Brinell scale | HBW2.5/187.5、HBW10/250、HBW10/500、HBW5/750、HBW10/1000、HBW10/3000 |
| test force | 187.5kgf(1839N)、250kgf(2452N)、500kgf(4903N)、750kgf(7355N)、1000kgf(8907N)、3000kgf(29420N) |
| loading method | Automatic loading, foot switch control |
| Maximum height of specimen | 300mm |
| Workbench size | 400*380mm |
| Measurement unit | 0.005mm |
| Load time | 15S (adjustable) |
| 15S (adjustable) | 8~650HBW |
| Microscope magnification | 20X |
| execution standard | EN, ISO 6507, EN ISO 6506, ASTM E-384, ASTM E-10-08, ASTM E-384 GB/T231.2，JJG150 |
| Distance from the center of the indenter to the body | 210mm |
| Hardness reading | Look up the table or use it with the Brinell measurement system |
| Power Supply | AC220+5%,50~60Hz |
| Dimension | 550*236*750mm |
| Host Weight | 123kg |
Packing list
Whole machine X1, standard Hardness block X3, fuse 2AX3, power cord X1, carbide ball indenter X3, 20x reading Microscope X1, 400 * 380mm workbench X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/15549/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
