Specifications
| test force | 1.96、4.90、9.80、29.4、49、98N |
| Test force application method | Automatic loading and unloading test force |
| Microscope magnification | 100X (for observation), 200X (for measurement) |
| Test force holding time | 0~60s (can also be arbitrarily determined according to needs) |
| Minimum resolution of micrometric indentation | 0.01μm |
| Maximum height of specimen | 200mm |
| Maximum width of specimen | 320mm |
| Host Weight | About 60Kg |
| Power Supply | AC220V/50Hz |
| Dimension | 520* 320*650mm |
Packing list
Machine X, screw batch X2, horizontal adjustment screw X4, power cord X1, computer X1, Optical inspection connector X1, CCD camera X1, image analysis software X1, level X1, spare fuse core (2A) X2, Vickers Hardness block X2, 10x digital micrometer eyepiece X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/15596/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
