AOLONGXINGDI HB-62.5 Small load Brinell Hardness Tester

The maximum height of the specimen of the AOLONGXINGDI HB-62.5 small load Brinell Hardness Tester is 160mm, and the distance from the indenter to the wall is 135mm. The HB-62.5 is a new type of brinell Hardness Tester using precision mechanical technology and photoelectric technology.

Model：

HB-62.5

Certificate

AoLongXingDi

Contact

Details SPEC CAT

AoLongXingDi HB-62.5 Brinell Hardness TesterSPEC

AoLongXingDi HB-62.5 Brinell Hardness TesterDetails

AoLongXingDi HB-62.5 Brinell Hardness TesterPacking list

SKU: NB015601

test force: 61.25N(6.25kgf),98.07N(10kgf),153.2N(15.625kgf), 294N(30kgf),306.25N(31.25kgf),612.9N(62.5kgf)

execution standard: EN, ISO 6507, EN ISO 6506, ASTM E-384, ASTM E-10-08, ASTM E-384 GB/T231.2，JJG150

Maximum height of specimen: 160mm

Head to wall distance: 135mm

Dimension: 250*550*650mm

Test force holding time: 5~60s

Test force application method: automatic

Microscope magnification: 40x，100x

Hardness Measurement range: 8-650 HBW

Power Supply: AC220V/50HZ

Weight: 45kg

HB-62.5

Brinell Hardness Tester

Introduction

HB-62.5 Small Load Brinell Hardness Tester is a new type of Brinell Hardness Tester using precision mechanical technology and photoelectric technology. The machine is controlled by an embedded microcomputer, suitable for cast iron, non-ferrous metals and their alloys, all kinds of annealed and tempered steel, especially suitable for softer metals such as pure aluminum, lead, tin hardness testing, is a scientific research institutions, enterprises and quality inspection departments for research and testing of the satisfactory Brinell hardness testing instrument

Features

●Adjust the intensity of the measurement light source

●Real-time display of test environment temperature

●Hardness test data is printed, which is easy to use

●High measurement accuracy

Standard configuration
name	quantity	name	quantity
Ф1mm steel ball indenter	1 pc	Ф2.5mm steel ball indenter	1 pc
Ф5mm steel ball indenter	1 pc	Large, medium-flat, V-shaped test bench	3 pcs
Brinell hardness block	2 pieces	weight	1 set
fuse	2 pcs	Power cord	1 root
Instruction manual	1 serving	Product Certificate	1 serving
Thermal printer paper	1 volume
