Specifications
| Measurement range | 0.8~ 300Mm (steel) |
| Display resolution | 0.1mm |
| Measurement mode | There are two Operating Modes of thickness measurement: single-point thickness measurement and scanning thickness measurement |
| Storage Capacity | Can store 20 sets (up to 100 Measured values each) of thickness measurement data |
| Speed of sound | 1000~9999m/s |
| Display | High contrast ratio segment LCD display, high luminance EL backlight |
| Power Supply | 2 AA alkaline batteries |
| Operating Time | More than 100h (when the backlight is not turned on) |
| Host size | 150*73.5*31mm |
| Weight | 185G (without battery) |
| error of indication | +/- (0.5% H + 0.1) mm, H is the actual thickness of the measured object |
| Measurement speed | Single point measurement 4 times per second, scanning mode 10 times per second |
| unit system | Metric or imperial system, metric and imperial systems can be freely converted |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/15666/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
