Specifications
| Display | LED LCD |
| Power Supply | ① Large Capacity lithium battery, no Memory effecy, continuous work for more than 8 hours; ② 220V AC (with power adapter) |
| Transmit pulse | Square wave, emission Voltage 25V~ 400V continuously adjustable, step 25V, width 30ns~ 1000ns continuously adjustable, step 5ns |
| Operating Mode | Single, double |
| impedance matching | 100Ω、400Ω |
| Gain range | 0.0~110.0dB (step 0.1dB, 1.0dB, 2.0dB, 6.0dB) |
| band selection | Divided into 0.5~ 4MHz, 2~ 8MHz, 0.5~ 20MHz three gears |
| Detection method | Positive half wave, negative half wave, full wave, radio frequency |
| Pulse translation | -45~9999mm |
| Probe zero | 0~999.99μs |
| Pulse, repeability Frequency | 25~ 1000Hz, automatic and manual adjustment methods |
| Vertical Linearity | ≤3% |
| Horizontal Linearity | ≤0.3% |
| Sensitivity margin | > 60dB (200φ 2 flat bottom hole) |
| resolution | ＞36dB |
| Dynamic range | ≥32dB |
| digital suppression | (0-99) %, does not affect linearity and gain |
| RF Output Impedance | 50Ω |
| electrical noise level | <10% |
| B imagery | Yes. |
| pulse amplitude | No adjustable |
| digital filtering | none |
| Crazing bathymetry | none |
| surface correction | none |
| Detection Wizard | none |
| pulse amplitude | No adjustable |
| pulse width | Adjustable |
| Scanning range | 0~5000mm |
| frequency band range | 0.2-20 MHz |
| Display | LED LCD |
| DAC Linear dispersion | Yes. |
| AVG Linear dispersion | Yes. |
| standard | All standards |
| waveform freezing | Yes. |
| Waveform playback | Yes. |
| channel | 100 |
| waveform | 1000 |
| video | The whole process can be recorded. |
| Automatic calibration | Yes. |
| noise suppression | Yes. |
| echo envelope | Yes. |
| Automatic gain | Yes. |
| analysis software | Yes. |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
