Specifications
| Oscillation mode | orbital |
| Maximum configuration | 384*60ul |
| Dimensions | 127*85*86mm |
| Net Weight | 1.1kg |
| Power | Input: 100-240VAC 50/60Hz, Output: 9VDC 1.5A |
| Oscillation Frequency | 300~1800rpm |
| Rotation speed | 1800r/min |
| LED display | Yes |
| operating temperature | 5℃ -40℃ |
| Noise level | ＜60dB |
| Recommended board size | 127.76×85.48mm |
| USB mode | yes |
Packing list
host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
Non-artificially caused product quality problems, the manufacturer provides 1 year free warranty service.
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/15793/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
