JINGHAI NDJ-8S digital display Rotational Viscometer measurement range 1~ 2000000m · Pas

Digital display, measurement range 1~ 2000000mPa · s, rotor specifications 1 #, 2 #, 3 #, 4 #(0 #optional), reproducibility +/- 0.5% F.S, measurement accuracy +/- 2% F.S.
Model：
Certificate
Contact
Details SPEC CAT OI
Similar products

JINGHAI NDJ-8S Rotational ViscometerSPEC

JINGHAI NDJ-8S Rotational ViscometerDetails

JINGHAI NDJ-8S Rotational ViscometerPacking list

SKU
NB015983
display mode
digital explicit
Measurement Range
1~2000000mPa·s
Rotor specification
1 #, 2 #, 3 #, 4 #(0 #optional)
reproducibility
±0.5%F.S
measurement Accuracy
±2%F.S
Power Supply
Power adapter is standard (input 220V +/- 10% 50 +/- 1Hz)
Rotor speed
0.3/0.6/1.5/ 3/6/12/30/60rpm
NDJ-8S
Rotational Viscometer
Digital display, measurement range 1~ 2000000mPa · s, rotor specifications 1 #, 2 #, 3 #, 4 #(0 #optional), reproducibility +/- 0.5% F.S, measurement accuracy +/- 2% F.S.
JINGHAI NDJ-8S digital display Rotational Viscometer measurement range 1~ 2000000m · Pas Picture

Features

NDJ/SNB series digital (LCD) viscometer (VISCOMETER) is a digital viscometer with a 16-bit microcomputer processor as the core of the stepper motor with high subdivision drive and digital liquid crystal with blue backlight function. The speed is stable and accurate, the key is clearly marked, the program design, the operation is simple, the alarm function, the screen directly displays the viscosity, speed, percentage torque, rotor number and the maximum viscosity value that can be measured by the selected rotor at the current speed. The main control board and subdivision driver board all adopt SMD technology, and the circuit design adopts the current professional microcomputer processor, and the structural layout is reasonable and compact. The full scale and linearity of each gear of the instrument are all measured and corrected through the PC interface, and its measurement performance and function have reached the same professional level abroad.

Shanghai Jinghai NDJ-8S Rotational Viscometer

Optional

> Ultra Low Viscosity Adapter (ULA)

> Standard oil

> Remote control operator

> Mini-sample adapter

> Printers

> RTD temperature probe(sMALL SAMPLE ADAPTER)

> Dedicated viscosity measurement thermostatic sink > heater


FAQ
QWhat is the general viscosity range when an ultra-low viscosity adapter is used?
A There is no ultra-low annual adapter, there is a small sample adapter, that is, the solution is between 10ml-20ml.
QTo test lye, NAOH aqueous solution of Viscometer, very low viscosity 3.5-4
A After NDJ-5S and 8S are equipped with No. 0 rotor, they can be detected for viscosities above 1.0.
QFind a rotational viscometer for JJG1002
A This NDJ-8S rotational viscometer is.
QDoes this NDJ-8S Viscometer have any requirements for the capacity of the sample tank?
A Hello, it is recommended to choose a sample tank with an inner diameter of ≥ 70mm, generally using a 400ml beaker container. It is not recommended to use a beaker that is too small, which may make the measurement result too large.
QHow many rotational speeds are available for Jinghai's NDH-8S swirl/spin viscosity meter?
A Hello, the optional speed is 0.3, 0.6, 1.5, 3, 6, 12, 30, 60rpm.
QDo Spinning & weaving dyestuff, want to find automatic digital display Viscometer, NDJ-8S Viscometer can?
A Hello, yes, but you need to confirm your test viscosity range again.
