Specifications
| Detection gas | TVOC |
| range | 0~2ppm |
| resolution | 0.001ppm |
| Response time | ≤ 20 seconds (T90) |
| linearity error | ≤±1% |
| precision | ≤ ± 3% (depending on the specific Sensors) |
| Zero drift | ≤±1%(F.S/年) |
| recovery time | ≤ 20 seconds |
| Sexual repeability | ≤±1% |
| Gas expansion | Supports 1-5 Sensors |
| Explosion-proof sign | CNEx16.0537 |
| Protection class | IP65 |
| Production license | Guangdong 00001052 (CMC metrology authentication) |
| Humidity measurement | Optional accessories, temperature detection range: -40~120 ℃, humidity detection range: 0-100% RH |
| Sampling method | Pump suction, built-in micro air pump |
| Detection mode | Real-time detection, Timer detection can be set |
| storage mode | Real-time storage and Timer storage can be set; 120,000 groups of data can be stored, and historical data can be viewed on the screen |
| Operating Temperature | -30~60℃ |
| Relative Humidity | ≤ 95% RH, no condensation |
| Operating Pressure | -30Kpa ⃣ 100Kpa |
| Power | 4000mA Rechargeable Polymer Battery |
| Dimensions | 180*85*55mm |
| Execution standards | GB3836.1-2010 "Explosive environments - Part 1: Equipment - General requirements", GB3836.4-2010 "Explosive environments - Part 4: Equipment protected by intrinsically safe" i " |
| Optional range | 0-2、10、50、100、200、500、1000、2000、5000、6000、10000ppm |
Packing list
host X1, USB charger X1, calibration cover X1, instrument case X1, manual X1, certificate X1, warranty card X1.
After-sales instructions
Warranty days: 365 days
The warranty period of the instrument is one year (one year free warranty, except for damage caused by human causes), and the damaged parts will be replaced free of charge during the warranty period. The guaranteed supply time of the parts supporting the instrument is 5 years, and the price of the corresponding consumables and spare parts remains unchanged for 3 years.
