Specifications
| Coating method | Bar + drawdown blade |
| Drawdown blade Accuracy | ±0.05mm |
| Drawdown blade thickness range | 0~10Mm drawdown blade can be lifted |
| Coating speed | 5~ 200Mm/s (< 5mm/s can be customized) |
| Coating size | 600*1000mm |
| Appearance structure | desktop |
| Mayer Rod Thickness Range | 1~ 517.5 μm (Spreader thickness according to bar model) |
| Host Power Supply | 220V 50Hz |
| speed control | Infinitely variable speed |
| Coating table material | aluminum alloy |
| Mayer Rod Accuracy | ±0.05mm |
| customizable function | Automatic feeding, air injection system device, UV solid inclusion device |
| Speed regulation Accuracy | 1mm/s |
Packing list
Machine x1, bar x1, Drawdown blade x1, manual x1, certificate x1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/1610/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
