Specifications
| Calibrated mode | Factory calibrated, zero and up to four calibrated points, if no substrate is used, calibrated by coating (CTC) |
| Alarm function | Optical and audible signal alarms when limits are exceeded |
| Unit display | μm/mm/cm/mils/inch |
| statistical function | kvar, n, max., min. kvar, n, max., min |
| compensation function | Used to add/subtract a constant value from a reading |
| Interface | USB and Bluetooth 4.0 |
| Data storage | 200W, can be grouped over 9500 |
| Power Supply | 3 * AA (LR06) battery, USB |
| Standards | DIN EN ISO 1461, 2064, 2178, 2360, 2808, 3882; ISO 19840; ASTM B 244, B 499, D 7091, E376 |
| Display screen | 53 x 46 mm, backlit |
| Operating temperature | -10~60℃ |
| Storage temperature | -20~70℃ |
| Battery life | 150 hours (without backlighting) |
| Protection level | IP65 |
| Weight | 320G (including battery) |
| Dimension | 153*89*36mm |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/16221/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
