Specifications
| Detect gas | VOC |
| Range | 0~2000ppm |
| Accuracy | ＜±3%F.S |
| minimum reading | 1ppm |
| Response time | ≤60s |
| Sensors Life | 24 months |
| Sensors principle | Optical inspection |
| Power Supply | 24V Power Supply |
| Sampling method | diffusion |
| Operating Mode | Long-term continuous work |
| Connecting cable | National standard signal line ≥ 3 * 1.0mm ² |
| Connectivity | M20 * 1.5 male thread |
| Structural Materials | die casting aluminum |
| Explosion-proof sign | Exd Ⅱ CT6 |
| Protection level | IP65 |
| Operating temperature | -40~70℃ |
| Operating humidity | 0~90%RH |
| Dimension | 180*140*75mm |
| Weight | 1.1kg |
| transmission distance | ≤1200m |
| Installation method | Fixing bracket, tube mount, wall mount |
| Output signal | 4-20mA current signal |
| Detector input | three-wire system |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/16323/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
